- R-410A HFC refrigerant
- Complete factory charged, wired and run tested
- Scroll compressors with internal line break overload and high-pressure protection
- Two independent refrigerant circuits each with a scroll compressor provide two stage cooling operation
- Convertible airflow – vertical downflow or horizontal sideflow
- Capillary tube metering system on each circuit
- High Pressure and Low Pressure/Loss of charge protection standard on all models
- Solid Core liquid line filter drier on each circuit
- Single slab, single pass designed evaporator and condenser coils facilitate easy cleaning for maintaining high efficiencies
- Cooling operation up to 125 degree F ambient
- Foil faced insulation encapsulated throughout entire unit minimizes airborne fibers from the air stream
- Hinged major access door with heavy-duty gasketing
- Slide Out Indoor fan assembly for added service convenience
- Powder Paint Finish meets ASTMB117 steel coated on each side for maximum protection. G90 galvanized
- Base pan with drawn supply and return opening for superior water management
- Forkable base rails for easy handling and lifting
- Single point electrical connections
- Internally sloped slide out condensate pan conforms to ASHRAE 62 standards
- High performance belt drive motor with variable pitch pulleys and quick adjust belt system
- Permanently lubricated evaporator, condenser and gas heat inducer motors
- Condenser motors are internally protected, totally enclosed with shaft down design
- 2 inch filter standard with slide out design
- 24 volt control system with resettable circuit breakers
- Colored and labeled wiring
- Copper tube/Aluminum Fin indoor coil
- Aluminum MicroChannel outdoor coil(s)
- Supplemental electric heat provides 100% efficient heating
