| Model | LIV09AC230V1AS | LIV12AC230V1AS | LIV18AC230V1AS | LIV24AC230V1AS | ||
|---|---|---|---|---|---|---|
| System Type | Cooling Only | Cooling Only | Cooling Only | Cooling Only | ||
| Power Supply | Voltage | 208-230V / 60Hz | 208-230V / 60Hz | 208-230V / 60Hz | 208-230V / 60Hz | |
| Rated Current Cooling | Amps | 4 | 6 | 8 | 10.3 | |
| Cooling Capacity (Min-Max) | Btu/h | 9,550 (5,300-11,300) | 12,000 (5,500-13,500) | 18,000 (7,340-20,000) | 22,000 (8,630-23,200) | |
| SEER/EER | 15.1 / 9.7 | 16.0 / 9.2 | 16.0 / 10.9 | 15.6 / 10.2 | ||
| Indoor Unit | LIV09AC230V1AH | LIV12AC230V1AH | LIV18AC230V1AH | LIV24AC230V1AH | ||
| Air Flow - T/H/M/L | CFM | 306/277/253/218 | 335/277/253/218 | 506/459/383/324 | 588/471/412/353 | |
| Sound Pressure Level - T/H/M/L | db (A) | 43/40/37/34 | 44/42/39/36 | 48/42/39/36 | 52/46/42/36 | |
| Unit Size (WxHxD) | Inches | 33 5/16 x 11 x 7 1/8 | 33 5/16 x 11 x 7 1/8 | 37 x 12 x 8 | 39 11/16 x 12 3/8 x 8 11/16 | |
| Package Size(WxHxD) | Inches | 36 3/16 x 14 5/8 x 10 3/16 | 36 3/16 x 14 5/8 x 10 3/16 | 40 x 15 1/8 x 11 13/16 | 42 3/8 x 15 11/16 x 13 | |
| Net/ Gross Weight | Pounds | 20 / 27 | 22 / 29 | 27 / 33 | 33 / 41 | |
| Outdoor Unit | LIV09AC230V1AO | LIV12AC230V1AO | LIV18AC230V1AO | LIV24AC230V1AO | ||
| Compressor Type | G10 Inverter - driven Rotary Compressor | G10 Inverter - driven Rotary Compressor | G10 Inverter - driven Rotary Compressor | G10 Inverter - driven Rotary Compressor | ||
| Sound Pressure Level | db(A) | 52 | 53 | 56 | 59 | |
| Unit Size (WxHxD) | Inches | 28 x 21 11/16 x 12 1/2 | 28 x 21 11/16 x 12 1/2 | 37 5/8 x 27 5/8 x 15 5/8 | 37 5/8 x 27 5/8 x 15 5/8 | |
| Package Size (WxHxD) | Inches | 30 1/2 x 23 7/8 x 13 13/16 | 30 1/2 x 23 7/8 x 13 13/16 | 40 1/2 x 29 1/2 x 18 | 40 1/2 x 29 1/2 x 18 | |
| Net / Gross Weight | Pounds | 61 / 65 | 65 / 70 | 97 / 106 | 108 / 118 | |
| Refrigerant / Charge | oz. | R410A / 26.1 | R410A / 35.3 | R410A / 42.3 | R410A / 56.4 | |
| Line Set Size, Liquid - Suction | Inches | 1/4" - 3/8" | 1/4" - 3/8" | 1/4" - 1/2" | 1/4" - 5/8" | |
| Pre-Charge | Feet | 25 | 25 | 25 | 25 | |
| Max. Line Run | Feet | 50 | 66 | 82 | 82 | |
| Max. Elevation | Feet | 33 | 33 | 33 | 33 | |
| MCA | Amps | 10 | 10 | 14 | 15 | |
| MOCP | Amps | 15 | 15 | 20 | 25 | |
| Wire Size / # Wires | AWG14 / 4 | AWG14 / 4 | AWG14 / 4 | AWG14 / 4 |
